Traditional Fencing Featherboard

COVERED BY JACKSONS 25 YEAR GUARANTEE

25 Year Guarantee

Traditional Featherboard Fencing

  • Matching gates available
  • Post are 125 x 100mm section for extra strength
  • Featherboard Fencing (non panel form)
  • Featherboard Fencing is supplied in Jakcure® treated softwood with a sawn finish
  • Quick and easy to install
View products Product information

WAS

EXC VAT

INC VAT

NOW

EXC VAT

INC VAT

Number
Product
Add to Basket
The pales are taper sawn, two from a 100 x 22mm section board. The pales are finished 150mm shorter than the height of the fence and stand on a 150mm gravel board as standard.

Posts
At Jacksons we sell two types of posts for Traditional Featherboard fencing and these are, corner end posts and inter-posts.

Inter posts are 125 x 100mm section, for extra strength. Posts are recessed for the rails. Post tops are weathered.

Corner posts are 125 x 125mm section.

  • 1.8m post for 1.2m fence have two recesses. Inter Post 230100, Corner Post 230800
  • 2.4m post for 1.5m fence have three recesses. Inter Post 230200, Corner Post 230900
  • 2.7m post for 1.8m fence have three recesses. Inter Post 230300, Corner Post 231000

Note:

When ordering Featherboard pales the code and price refers to a single pale, the reference to "(2ex)" means the pale is cut diagonally from a plank 100mm x 22mm section therefore creating 2 pales from 1 plank.

To calculate the materials you will need:

  • Allow one post and 29 pales for every 2.4m bay plus one extra post for the end of the run
  • For the 1.2m fence allow 2 rails and for the 1.5m & 1.8m fences allow 3 rails per section
  • You will also need 1 gravel board (230700) for every section

Remember: to add 1 extra post to complete the fence run. 75mm nails are needed for attaching rails and gravel boards, 1kg for 23m. 50mm nails for attaching pales, 1kg for 9m.

Use our calculator (icon above) on this page to find the required items. Please note that the calculator will only work out the amount of 2.4m sections and items needed, not the exact amount of boards needed for the run length entered.

Capping for traditional Featherboard fencing:

Planed timber capping rail (232200), with counter rail (232100) and two "L" shaped brackets (645100) are available for the complete kit use code: 232200BM

The table below will assist you to establish which posts to use, the Gravel Boards (gb) and Rails are common to all heights.



Fence Height

Pale Height

Pales

Inter Post

Corner Post

Gravel Board

Rail

Capping Rail Kit

1.2m with gb

1.05m

230400

230100

230800



1.5m with gb

1.35m

230500

230200

230900



1.8m with gb

1.65m

230600

230300

231000



0.9m no gb

0.9m

232300

230100

230800



1.2m no gb

1.2m

232400

230100

230800



1.5m no gb

1.5m

232500

230200

230900



1.8m no gb

1.8m

232600

230300

231000



All



230700

231400

232200BM


Other systems to match your existing fencing are available, please phone our sales team 0800 408 2234 to clarify if unsure.

Capping for traditional Featherboard fencing:

Planed timber capping rail (232200), with counter rail (232100) and two "L" shaped brackets (645100) are available for the complete kit use Code: 232200BM

We also have a full range of Featherboard Panels for use with slotted posts, please click the link below



Products in Traditional Fencing Featherboard

Buying multiple products?
Just update the quantities of each item you wish to buy and click 'Add all to basket'
100mm hex screw
100mmLong Timber Screw Hex Head

Code: 171709

£0.25 EXC VAT

Buying multiple products?
Just update the quantities of each item you wish to buy and click 'Add all to basket'
