Tartan Trellis is part of our premium range of trellis. It's framed on all four sides and battens are fixed in place using scrails for strength and durability. Tartan trellis is a refreshing spin on a traditional square trellis with a little more privacy. Made by placing battens at irregular spacings, we’ve created a new style that is different from all square and diamond offerings. The pattern is reminiscent of plaid or tartan, hence the name.

A truly decorative panel that will add a focal feature to any garden.

Tartan Trellis Specification

Our premier tartan trellis panels are made using our trademark vacuum pressure treated Jakcure® softwood timber and are guaranteed for 25 years. Constructed using stainless steel fixings, our trellis panels are built to last.

• All timber used throughout is superior quality Jakcure® finished softwood, guaranteed for 25 years
• Planed finish
• Tartan Trellis panel framing is 45 x 51mm for extra strength
• Due to design this trellis panel is only available in 1.83m x 1.83m
• For use with our slotted Jakpost®

Fence Post Options: Standard Slotted Jakpost®, Heavy Duty Slotted Jakposts®, Mi-T® Metal Post​

​Gravel board options:  Standard Gravel Board, Hedgehog Friendly Gravel Board

To meet the conditions of the 25 year guarantee, gravel boards are required where panels are in contact with the ground.

​Installation Advice

Installation Instructions​

Reducing the width of a trellis panel – All trellis panels are 1.83m wide as standard; if you require a narrower fence panel, you can cut the fence panel down on site using our cut down kit. Please remember to treat any cut ends with Jakcure Cut Treatment, to ensure you adhere to our 25 year guarantee terms and conditions.

Recommended Fixings

We recommend using 6 screws per panel or 12 per panel if using capping rails plus an additional 4 per gravel board. 60mm, stainless steel, self-drilling countersunk screws are available in packs of 100 or 200 to secure panels to posts. Panels should be screwed to the posts to secure the fence run

Explore our wooden trellis gate range below. There are no matching gates for this specifc trellis but we suggest a standard lattice or square trellis gate.

Trellis Gates

Tartan trellis panels are often used with our slotted Jakposts® and panels to create either screens or fencing.

Fence posts

We also manufacture, Square, Diamond, and Lattice styles of Trellis; explore the different types below.

Trellis Panel Range

Gravel boards need to be used when panels are in contact with the ground as part of the 25 year Jakcure guarantee Ts&Cs.

Gravel Boards
