Shadowline™ Fence Panels
About the panel
Built with architectural design in mind, our Shadowline™ Panel has a modern unique profile which provides a dynamic central shadow gap between each board, free of any visible fixings, to provide a seamless contemporary finish.
These contemporary panels offer you the option to install a solid privacy style fence with no lines of sight through the panel which creates a clear shadow line between each board.
Panel Specification
Our Shadowline fence panels are made using our trademark vacuum pressure treated Jakcure® softwood timber and are guaranteed for 25 years. Constructed using stainless steel fixings, our fence panels are built to last.
Shadowline panels are constructed using ‘Z shaped’ 144mm x 26mm horizontal boards which overlap. Each panel is manufactured using 4x 70mm x 24mm back rails. The density and thickness of the boards make this panel extremely heavy duty.
- Panels are 1.83m wide
- Panels are 51mm wide
- Z shaped horizontal boards 144mm x 26mm
- 4 x 70mm x 24mm back rails
- Supplied in two shorter panels to be combined during installation
- Our 0.66m high panels are made with 5 boards.
- Our 0.91m high panels are made with 7 boards.
To achieve a taller fence, the panels can be stacked - for example stacking 2x 0.91m panels will give you 1.8m high approx. You could use 2x 0.66m panels for a 1.3m high panel approx or alternatively combine one of each height for 1.55m. It is not obvious in any way that these panels are stacked and once installed they will appear as one continuous panel. These can be stacked up to 2.4m tall, using heavy slotted posts.
Please Note: dimensions may increase by 6% when first delivered as our treatment process can temporarily cause the product to swell.
Fence Post Options – Standard Slotted Jakpost® ,Heavy Duty Slotted Jakposts®
Gravel board options- Standard Gravel Board , Hedgehog Friendly Gravel Board
To meet the conditions of the 25 year guarantee, gravel boards are required where panels are in contact with the ground.
Installation Advice Installation Instructions
Reducing the width of the fence panel – All fence panel are 1.83m wide as standard, if you require a narrower fence panel, you can cut the fence panel down on site using our cut down kit. Please remember to treat any cut ends with Jakcure Cut Treatment, to ensure you adhere to our 25-year guarantee guidelines.
Recommended Fixings
We recommend using 6 screws per panel or 12 per panel if using capping rails plus an additional 4 per gravel board. 60mm, stainless steel, self-drilling countersunk screws are available in packs of 100 or 200 to secure panels to posts. Panels should be screwed to the posts to secure the fence run.
Capping Rails are recommended with our Shadowline panels. Use the buttons below to see our options
Shadowline Fence Panels are designed to be used with our slotted Jakposts.
Gravel boards need to be used when panels are in contact with the ground as part of the 25 year Jakcure® guarantee. More details can be found on our Jakcure T&C's page.
